Prism-Glow Sheet - Light reflective and glow-in-the-dark in one piece

Glow-in-the-dark product of Prism Glow Series has special properties which can “glow in the dark and reflect light incident” on the same piece of goods. This is special feature goods that serves wider range of user application. It is good for using both indoor and outdoor such as making glow-and-reflective traffic sign, glow-and-reflective guidance signage, including safety enhancement application for outdoor activities in the dark environment such as adhere on bicycle frame, safety helmet, bag, and etc. Also, it can be used to make special gadget like glow-and-reflective armband which is ready-to-use product from LumiGLOW®.



Unique characteristic of Prism-Glow Sheet

  • Two functions in the same piece; glow-in-the-dark and light reflective
  • Easy to use, convenient, adhere to any surface as needed
  • Luminance brightness meets global standards
  • Absorb any kind of light energy; sunlight, LED lamp, or fluorescent lamp
  • Special unique material from Japan
  • Luminance level as same as High Glow class, last long for more than 12 hours under lab condition
  • Made from water-resistance coated pigment. Can be use both indoor and outdoor.
  • Easy cleaning with glossy surface, just easily wipe out even there is smut on surface
  • Top surface material is PET which has better temperature tolerance than PVC. This allows longer life time than ordinary PVC sticker.



"Enhance ultimate level of safety with glow-and-reflective sticker by LumiGLOW®"

Able to be glow in the dark and reflect light incident on the same piece



There are many products in Prism Glow Series from LumiGLOW®.



Prism-Glow Sport Armband

Glow and reflective armband
  • Convenient armband for enhancing safety of your favourite activity in the dark environment
  • Width 25mm x Length 300mm

Prism-Glow Sheet

Glow and reflective sticker in one piece
  • Large sticker sheet which can reflect light and glow-in-the-dark
  • Suitable for massive production of glow-and-reflective goods
  • Make traffic signage which can reflect light and glow-in-the-dark
  • Total width of 1.22 meter

Prism-Glow Signboard

Glow and reflective signage
  • Reflect light as normal traffic signage
  • Glow in the dark without using Electrical power
  • Good for using in rural area without light pole
  • Can be customized as customer requirements





LumiGLOW® product has weatherability test report to ensure product endurance and many more tests.

LumiGLOW® passed various global standards; for example

  • Water resistance test: Submerge a piece of LumiGLOW® sheet for 1 month. It is found that the glowing performance has no significant change.
  • Weatherability Test: Do cycle test according to JIS A 1415 standard by spray water for 18 minutes and then shine light with intensity of 180W/m2 by Xenon arc lamp for 102 minutes under ambient temperature of 63 Celcius centigrades and 50% humidity. There is no significant change in glowing performance after repeat this cycle for 1,000 hours (equivalent 5 years of outdoor usage).
  • Adhesive Test: Perform test by following methodology in JIS Z 0237 standard for both indoor and outdoor conditions.
  • Flamability Test: Perform test by following methodology in ASTM E 162-95 standard.
  • Smoke Intensity Test: Perform test by following methodology in ASTM E 662 standard.
  • Toxic Gas Generation Test: Perform toxic gas generation by following methodology in SMP-800C standard
  • Luminance Test: Perform test by following methodology in various global standards; JIS Z 9107, DIN 67510, ISO 17398
  • Luminance Test (Outdoor): Perform test by following methodology in JIS Z 9098 standard and ISO 22578 standard
  • Harzardous substances detection: Perform harzardous substances according to RoHS 2.0 standard which is widely applied in US, Europe, and worldwide in order to ensure that glow materials and products from LumiGLOW® and Nexit® are highly safe for human, animal-being and environment (Green product).
and etc.



Luminance level of Prism-Glow Sheet

Luminance of product in Prism Glow Series is equivalent to High glow class of LumiGLOW® sheet which is last long more than 12 hours under the lab condition.
Visible condition in completely dark environment is set to luminance level of 3 mcd/m2 or above.
Remark: 3 mcd/m2 is the minimum level which human can notice spot in the completely dark environment. This test is performed by doing blind test for 10 persons.

Luminance level of Prism-Glow Series



Usage example of Prism-Glow Sheet

  1. Use as noticable spot in order to prevent accident in the dark and road-side accident
  2. Adhere to bicycle frame, motorcycle, bag, shoes, safety helmet or armband.
  3. Use to make glow and reflective signage

ตัวอย่างการใช้งานผลิตภัณฑ์ Prism-Glow Series
ตัวอย่างการใช้งานผลิตภัณฑ์ Prism-Glow Series
ตัวอย่างการใช้งานผลิตภัณฑ์ Prism-Glow Series
ตัวอย่างการใช้งานผลิตภัณฑ์ Prism-Glow Series
